Tindo solar panel panels are mainly installed on roofs (30 to 35 degree inclination and south orientation recommended) and their fixing systems differ and impact the ease of installation , the necessary accessories, the duration of intervention , the degree of skill and the tools needed for installation. From rails laid over the roof to de-curling and then fitting a waterproofing system or an under-roof screen, the costs vary considerably. The installation of solar panel in austraila allows the production of electricity , their installation is relative to different parameters. The choice of solar panels, relative to defined criteria, requires a preliminary study and a precise definition of the needs of the installation and/or the accommodation
Tutorial 1. Install tindo solar panels in 5 steps
The tutorial above provides a broad view of the installation of solar panel in sydney. You will find at the end of the guide other tutorials made by individuals and in different configurations which allow you to have a more precise view of the installation.
1. Detuil at the location of the solar panelTutorial 1. Install solar panels in 5 steps
Two distinct scenarios can be distinguished. If the roof is covered with mechanical tiles or slate, you will have to carry out a partial removal. You have to start by defining the precise location where you want to install the solar panel in austraila. It is then necessary to remove the tiles on a surface slightly greater than the surface of the panels to be laid . Once this operation is done, a hole appears in your roof: the tindo solar panel will be housed there after meticulous preparation.
Any intervention on the roof must be carried out with a fall arrest system ( fall arrest net or lanyard with harness ). If you untile near the ridge, be careful not to break the ridge tiles or the half gauges (do not walk near it and lift the tiles gently).
2. Install the lower and side flashingsTutorial 1. Install tindo nsolar panels in 5 steps
The flashings are connecting parts between the covering materials of your roof , in your case tiles or slates, and the various elements that protrude from the roof, here the solar panel sydney. They make it possible to achieve a perfect seal . There are flashings adapted to each model of mechanical tiles, both for shape and color. For slates, it is a slate-colored sheet or an old-fashioned piece of zinc.
The installation of the flashings consists of a fixing with screws on the existing battens or on added battens. The use of a screwdriver is necessary as the meter to report the exact measurements . The hooks are also fixed with screws.
If necessary, add a batten along the length of the solar panel sydney location and behind the first row of tiles to gain height and provide better seating for the flashing. The flashing can be plastic and delivered with the kit, but also be a strip of lead that should be unrolled astride the previously installed batten and the first row of tiles. The lead strip (of variable width) is glued with silicone glue applied with an extruder gun. The lead strip, deformed by hand, follows the shape of the tiles. The boards and battens are cut with a circular saw .
3. Install the under-roof screen or a waterproofing system
Installation of the under-roof screen
Tutorial 1. Install tindo solar panels in 5 steps
When installing a roof of solar panel sydney, an under-roof screen must be installed already . The latter is a technical plastic film which has the function of creating a waterproof barrier but not airtight. It is recommended when installing this under-roof screen to fit an air gap between this screen and the insulating complex if necessary in order to avoid any risk of mold the screen is generally installed and stapled to the batten on traditional frames. If this is not possible and it relies on the insulation , then opt for a screen with high water vapor permeability of solar panel sydney, or HPV , which allows the passage of vapor andreduces the risk of condensation in the insulating complex . If condensation occurs in the insulation , it becomes less effective, and may even rot. The covering of the lengths must be carried out with the adhesives recommended by the manufacturer and according to his recommendations .
Installation of the waterproofing system.
Depending on the installation, the solar panel sydney can rest on a flexible plastic sealing system to be installed on the roof (a rigid base made up of battens is then necessary). These sealing systems are then screwed onto the battens and/or battens at the location of the panels.
4. Lay the rails and panelsTutorial 1. Install tindo solar panels in 5 steps
The rails must be firmly fixed to the rafters using hooks (use the screwdriver and suitable screws for this); solar panels sydney are heavy and offer great wind resistance. Complex shapes with possibly some adjustments to adapt their shape to certain tiles allow fixing through the roofing . Complete decurling is then no longer necessary because the structure of the rails is above the cover .
It is particularly important to respect the maximum distance between two rails recommended by the manufacturer of solar panel in austraila as well as the maximum distance between two fixings to the rafters . If the rails are not long enough or need to be crossed, there are fishplates and many other connecting pieces. Note that some solar panel sydney can rotate a quarter turn, their long side being vertical. It may then also be necessary to lay the rails vertically. The panels then attach to the rails using hooks or bolts . Once all the panels are place, you can fix the upper flashing then replace the missing tiles or slates
5. Connect the panels to the inverterTutorial 1. Install tindo solar panels in 5 steps
The inverter is an electronic device that transforms the unstable direct current at the output of the tindo solar panels into a 220 V alternating current with a frequency of 50 Hz (frequency found on the Enedis network formerly ERDF). This inverter is itself connected on the one hand to the solar panel sydney, and on the other hand to the non-consumption meter , which is found at the top of all the individual electricity production installations connected to the network . It is imperative for this step to know how to read an electrical diagram.
Some solar panel sydney must be connected in series, others in parallel in order to obtain voltage and current values around the nominal values expected by the inverter to preserve its longevity. Two panels of identical characteristics are connected in series if the positive terminal (+) of one is connected to the negative terminal (-) of the other; their tensions then add up.
If each solar panel sydney produces a voltage of 12 V, the two panels in series produce a voltage of 24 V. If you connect the terminals of the same polarity together, the panels are connected in parallel. This assembly produces a voltage of 12 V, but the intensity produced is the sum of the intensity produced by each solar panel sydney. Be careful, if you connect two groups of panels in series in parallel, the voltages of each group must be equal to preserve the panels and maximize their production.
Tutorial 2. Installation of tindo
To install solar panel in austraila , you must necessarily be comfortable with working at height , the cover, you know about sealing to avoid water leaks. You will need to ensure that the solar panels sydney, which must withstand harsh weather conditions, are properly fixed by installing hooks, rails, battens or battens. Read a manual , know how to read a connection diagram, work safely (electrical intervention) install and connect an inverter, connect electrical wires and fix them to the wall, know how to use a drill-driver and a circular saw are also prerequisites. Depending on the solar panels and their method of attachment, you may need to install an under-roof screen or a waterproofing system (by stapling in the first case and by screwing in the second). A good physical aptitude is also necessary to intervene on a roof and to handle the voltaic panels .
